CODE: FHU 021 03

Specialized tool for the prevention, combat and settlement of Forest Fires that in its metallic part is

provided with special tempered steels that allow handling materials fired or at high temperatures

without causing damage to their chemical and physical structure. Firebreak rake, used to rake mineral

soil, dig, roll logs and cut weeds. It has a handle of American ash for its flexibility and its resistance to

impacts. In addition to this tool, it is the one with the greatest drag in areas with a lot of plant material.

It has a total length of 143 + 1cm and a total weight of 1,650 kg + 100 gr. It has a 14 cm semi-conical

tube that in its widest part has an outer diameter of 3.8 cm, at the opposite end it has a slot in which a

curved plate is inserted and welded 5 cm wide by 8 cm long by 0.63 mm thick, the semi-conical tube

and the curved plate are made of AISI / SAE 1020 quality steel, its chemical composition is 0.18 to

0.23% carbon, 0.30 to 0.60% manganese, maximum 0.40 phosphorus and no more than 0.050%

sulfur.

On the end of the curved plate, 4 solid 1045 grade tempered steel teeth must be welded, which must

have a hardness of 48 to 52 degrees Rockwell C and be equidistant and should measure 17 cm in

width and at 4 cm they have a bend, each tooth should end in a point and should measure 15.3 cm

after the bend, and at the opposite end of the cube a wooden handle of 130 + 1 cm in length should

be inserted.

A wooden handle is inserted into the semi-conical tube, which is straight cylindrical, made of FAS

quality american ash wood, resistant to high impact, without notches or splinters, and without handles

or finials, the end of the user has a rounded finish

The total length of the tool is 143 + 1cm and the total weight is 1,650kg + 100gr
